I motori a gas della Waukesha sono famosi perché riescono a lavorare anche in condizioni di altro stress e gestiscono una vasta scelta di combustibili utilizzabili. Rappresentano una delle migliori soluzioni per generare energia. Sono creati per assicurare prestazioni di alto livello anche per le applicazioni più sofisticate, in isolamento e mission critical. Waukesha è sinonimo di alta resistenza, e rispettano i livello delle emissioni globali

Scopri quali sono i loro vantaggi

  • L’esperienza creata in più di un lustro di attività, e le tecnologie all’avanguardia sempre utilizzate nei motori VHP, generano un prodotto affidabile con costi di gestione ridotti al minimo;
  • Si può generare più energia grazie alla flessibilità nella scelta del combustibile
  • Certificati EPA con una tecnologia in grado d’essere sfruttata in diversi campi, che inizialmente erano ad avvio rapido con diesel, con emissioni e costi abbassati

Technical Data

Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375'' x 8.5 (238 x 216)
Jacket water system capacity 100 gal (379 L)
Lube oil capacity 190 gal. (719 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Four L7044GSI

With ESM2 and emPact Emission Control System
1,120 - 1,680 BHP (835 - 1,253 kWb)
waukesha engine VHP Series Four L7044GSI

Technical Data

Cylinders
V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 10.2:1
Bore & stroke 8.5” x 8.5” (216 x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Four L5794LT

With ESM
1,208 - 1,450 BHP (901 - 1,081 kWb)
waukesha engine VHP-Series-Four-L5794LT

Technical Data

Cylinders
Inline 6
Piston Displacement 3,520 cu. in.(58 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216)
Jacket water system capacity 48.5 gal. (184 L)
Lube oil capacity 72 gal. (273 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 129.14 (3,280) x 85.65 (2,175) x 81.34 (2,066)
Weights lb (kg) 16,000 (7,257)

VHP Series Four F3524GSI

With ESM2 and emPact Emission Control System
560 - 840 BHP (418 - 626 kWb)
waukesha engine VHP-Series-Four-F3524GSI

Technical Data

Cylinders
Inline 6
Piston Displacement 3,520 cu. in.(58 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216)
Jacket water system capacity 48.5 gal. (184 L)
Lube oil capacity 72 gal. (273 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 129.14 (3,280) x 85.65 (2,175) x 81.34 (2,066)
Weights lb (kg) 16,000 (7,257)

VHP Series Four F3524G

With ESM
345 - 460 bhp (257-343 kWb)
waukesha engine VHP-Series-Four-F3524G

Technical Data

Cylinders
Inline 6
Piston Displacement 3,520 cu. in.(58 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216)
Jacket water system capacity 48.5 gal. (184 L)
Lube oil capacity 72 gal. (273 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 129.14 (3,280) x 85.65 (2,175) x 81.34 (2,066)
Weights lb (kg) 16,000 (7,257)

VHP Series Four F3514GSI

With ESM2 and emPact Emission Control System
493 - 740 BHP (368 - 552 kWb)
waukesha engine VHP-Series-Four-F3514GSI

Technical Data

Cylinders
V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 10.2:1
Bore & stroke 8.5” x 8.5” (216 x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Four L5774LT

1,067 - 1,280 BHP (795 - 954 kWb)
waukesha engine VHP-Series-Four-L5774LT

Technical Data

Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Four L7042GSI S4

With ESM2 and emPact Emission Control System
987 - 1,480 BHP (736 - 1,104 kWb)
waukesha engine VHP-Series-Four-L7042GSI-S4

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalyst-out exhaust piping shown for illustrative purposes only.

Technical Data

Cylinders
V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 8.25:1
Bore & stroke 8.5” x 8.5” (216 x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,760 (11,230)

VHP Series Four L5794GSI

With ESM2 and emPact Emission Control System
920 - 1,380 BHP (686 - 1,029 kWb)
waukesha engine VHP-Series-Four-L5794GSI

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalyst-out exhaust piping shown for illustrative purposes only.

Technical Data

VHP L7044GSI EPA
Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting System 90 - 150 psi air/gas; optional 24V electric
VHP L5794GSI EPA
Cylinders
V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 8.25:1
Bore & stroke 8.5” x 8.5” (216 x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting System 90 - 150 psi air/gas; optional 24V electric

VHP Series Four L5794/L7044GSI-EPA

Multi-Fuel Mobile Power Generation
1,380/1,680 BHP (1,029/1,253 kWb)
waukesha engine VHP-Series-Four-L5794-L7044GSI-EPA

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalyst-out exhaust piping shown for illustrative purposes only.

Technical Data

VHP L7044GSI MOB
Cylinders
V12
Piston Displacement 115 L (7,040 cu. in.)
Compression ration 8:1
Bore & stroke 238 x 216 mm (9.375’’ x 8.5’’)
Jacket water system capacity 379 L (100 gal.)
Lube oil capacity 719 L (190 gal.)
Starting System 620 - 1034 kPa air/gas; optional 24V electric
VHP L5794GSI MOB
Cylinders
V12
Piston Displacement 95 L (5,788 cu. in.)
Compression ration 8.25:1
Bore & stroke 216 x 216 mm (8.5” x 8.5”)
Jacket water system capacity 405 L (107 gal.)
Lube oil capacity 719 L (190 gal.)
Starting System 620 - 1034 kPa air/gas; optional 24V electric

VHP Series Four L5794/L7044GSI-MOB

Multi-Fuel Mobile Power Generation
943/1,148 kWb (50 Hz @ 1,000 rpm)
waukesha engine VHP-Series-Four-L5794-L7044GSI-MOB

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalyst-out exhaust piping shown for illustrative purposes only.

Technical Data

Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting System 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Four L7044G

With ESM2
690 - 920 bhp (515 - 686 kWb)
waukesha engine VHP-Series-Four-L7044G

Technical Data

Cylinders
12V
Piston Displacement 13,048 cu. in. (214 L)
Compression ration 8:1
Bore & stroke 10.83” x 11.81” (275 x 300 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 220 gal. (883 L)
Fuel pressure range 50 – 60 psi (3.4 – 4.1 bar)
Starting system 150 psi (10.3 bar)
Dimensions l x w x h inch (mm) 188.8 (4,796) x 91.3 (2,320) x 126.4 (3,211)
Weights lb (kg) 54,000 (24,493)

275GL Series 12V 275GL+ Fuel Flex

Gas Engine with ESM 2
Constant Torque Ratings
3,750 bhp (2,796 kWb) @ 1,000 rpm
waukesha engine 275GL-Series-12V-275GL-Fuel-Flex

Image is representative of engine model.

Technical Data

Cylinders
12V
Piston Displacement 13,048 cu. in. (214 L)
Compression ration 9:1
Bore & stroke 10.83” x 11.81” (275 x 300 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 220 gal. (883 L)
Fuel pressure range 45 – 60 psi (3.1 – 4.1 bar)
Starting system 150 psi (10.3 bar)
Dimensions l x w x h inch (mm) 307 (7,801) x 94 (2,377) x 140 (3,556)
Weights lb (kg) 97,444 (44,200)

12V 275GL+

Enginator generating system
Constant Speed Ratings
50 Hz: 2,685 kWe @ 1,000 rpm
60 Hz: 2,410 kWe @ 900 rpm
waukesha engine 12V-275GL

Technical Data

Cylinders
16V
Piston Displacement 17,398 cu. in. (285 L)
Compression ration 8:1
Bore & stroke 10.83” x 11.81” (275 x 300 mm)
Jacket water system capacity 133 gal. (503 L)
Lube oil capacity 275 gal. (1040 L)
Fuel pressure range 50 – 60 psi (3.4 – 4.1 bar)
Starting system 150 psi (10.3 bar)
Dimensions l x w x h inch (mm) 237.4 (6,026) x 91.3 (2,320) x 126.4” (3,211)
Weights lb (kg) 65,320 (29,624)

275GL Series 16V 275GL+ Fuel Flex

Gas Engine with ESM 2
Constant Torque Ratings
5,000 bhp (3,728 kWb) @ 1,000 rpm
waukesha engine 275GL-Series-16V-275GL-Fuel-Flex

Technical Data

Cylinders
V16
Piston Displacement 17,398 cu. in. (285 L)
Compression ration 9:1
Bore & stroke 10.83” x 11.81” (275 x 300 mm)
Jacket water system capacity 133 gal. (503 L)
Lube oil capacity 275 gal. (1040 L)
Fuel pressure range 45 – 60 psi (3.1 – 4.1 bar)
Starting system 150 psi (10.3 bar)
Dimensions l x w x h inch (mm) 356 (9,054) x 101 (2,565) x 140 (3,556)
Weights lb (kg) 115,522 (52,400)

16V 275GL+

Enginator generating system
Constant Speed Ratings
50 Hz: 3,600 kWe @ 1,000 rpm
60 Hz: 3,200 kWe @ 900 rpm
waukesha engine 16V-275GL

Technical Data

Waukesha engine
F18GL/GLD
Cylinders Inline 6
Piston displacement 1,096 cu. in. (18 L)
Compression ratio 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 16 gal. (60 L)
Lube oil capacity 44 gal. (166 L)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water cooler
122 (3,350) x 54 (1,370) x 79 (2,000)
Radiator
167 (4,470) x 78 (1,980) x 99 (2,520)
Weights lb (kg) Water connection 8,900 (4,040)
Radiator 11,800 (5,360)

VGF18GL/GLD

Enginator generating system
240 - 315 kWe
waukesha engine VGF18GL-GLD

Technical Data

Waukesha engine
L36GSID
Cylinders V12
Piston displacement 2,193 cu. in. (36 L)
Compression ratio 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 44 gal. (166 L)
Lube oil capacity 86 gal. (326 L)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water cooler
152 (3,860) x 68 (1,720) x 96 (2,440)
Radiator
196 (4,980) x 105 (2,670) x 124 (3,150)
Weights lb (kg) Water connection 18,000 (8,170)
Radiator 23,580 (10,700)

VGF36GSID

Enginator generating system
450 - 620 kWe
waukesha engine VGF36GSID

Technical Data

Cylinders
16V
Piston Displacement 17,398 cu. in. (285 L)
Compression ration 9:1
Bore & stroke 10.83” x 11.81” (275 x 300 mm)
Jacket water system capacity 133 gal. (503 L)
Lube oil capacity 275 gal. (1040 L)
Fuel pressure range 45 – 60 psi (3.1 – 4.1 bar)
Starting system 150 psi (10.3 bar)
Dimensions l x w x h inch (mm) 237.4 (6,026) x 91.3 (2,320) x 126.4” (3,211)
Weights lb (kg) 65,320 (29,624)

275GL Series 16V 275GL+ ESM2

Gas Engine
Constant Torque Ratings
5,000 bhp (3,728 kWb) @ 1000 rpm
4,500 bhp (3,356 kWb) @ 900 rpm
3,750 bhp (2,796 kWb) @ 750 rpm
waukesha engine 275GL-Series-16V-275GL-ESM2

Technical Data

Waukesha engine
F18SE
Cylinders Inline 6
Piston Displacement 1,096 cu. in. (18 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 16 gal. (60 L)
Lube oil capacity 44 gal. (166 L)
Fuel pressure range 1.5 - 5 psi (10-32 kPA)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water connection
145 (3,683) x 62 (1,570) x 84 (2,135) Radiator
200 (5,068) x 78 (1,978) x 99 (2,502)
Weights lb (kg) Water connection 9,900 (4,491)
Radiator 13,600 (6,169)

VGF18SE

Enginator generating system
220 - 310 kWe
waukesha engine VGF18SE

Technical Data

Cylinders
12V
Piston Displacement 13,048 cu. in. (214 L)
Compression ration 9:1
Bore & stroke 10.83” x 11.81” (275 x 300 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 220 gal. (883 L)
Fuel pressure range 50 – 60 psi (3.4 – 4.1 bar)
Starting system 150 psi (10.3 bar)
Dimensions l x w x h inch (mm) 188.8 (4,796) x 91.3 (2,320) x 126.4” (3,211)
Weights lb (kg) 51,900 (23,541)

275GL Series 12V 275GL+ ESM2

Gas Engine
Constant Torque Ratings
3,750 bhp (2,796 kWb) @ 1,000 rpm
3,375 bhp (2,517 kWb) @ 900 rpm
2,812 bhp (2,097 kWb) @ 750 rpm
waukesha engine 275GL-Series-12V-275GL-ESM2

Image is representative of engine model.

Technical Data

Waukesha engine
H24SE
Cylinders Inline 8
Piston Displacement 1,462 cu. in. (24 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 20 gal. (75 L)
Lube oil capacity 56 gal. (212 L)
Fuel pressure range 1.5 - 5 psi (10-32 kPA)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water connection
163 (4,140) x 62 (1,570) x 84 (2,135) Radiator
203 (5,151) x 88 (2,232) x 111 (2,829)
Weights lb (kg) Water connection 13,100 (5,942)
Radiator 16,500 (7,484)

VGF24SE

Enginator generating system
295 - 410 kWe
waukesha engine VGF24SE

Technical Data

Waukesha engine
P48GSID
Cylinders V16
Piston Displacement 2,924 cu. in. (48 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 58 gal. (219 L)
Lube oil capacity 113 gal. (428 L)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water connection
176 (4,470) x 68 (1,720) x 96 (2,440) Radiator
228 (5,790) x 105 (2,670) x 136 (3,230)
Weights lb (kg) Water connection 23,000 (10,440)
Radiator 30,200 (13,700)

VGF48GSID

Enginator generating system
610 - 825 kWe
waukesha engine VGF48GSID

Technical Data

Waukesha engine
L36GLD
Cylinders V12
Piston Displacement 2,193 cu. in. (36 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 44 gal. (166 L)
Lube oil capacity 86 gal. (326 L)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water connection
152 (3,860) x 68 (1,720) x 96 (2,440) Radiator
196 (4,980) x 105 (2,670) x 124 (3,150)
Weights lb (kg) Water connection 18,000 (8,170)
Radiator 23,580 (10,700)

VGF36GL/GLD

Enginator generating system
500 - 645 kWe
waukesha engine VGF36GL-GLD

Technical Data

Waukesha engine
H24GL/GLD
Cylinders Inline 8
Piston Displacement 1,462 cu. in. (24 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 20 gal. (75 L)
Lube oil capacity 56 gal. (212 L)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water connection
143 (3,630) x 54 (1,370) x 79 (2,000) Radiator
183 (4,650) x 88 (2,240) x 112 (2,840)
Weights lb (kg) Water connection 12,210 (5,540)
Radiator 14,720 (6,680)

VGF24GL/GLD

Enginator generating system
325 - 425 kWe
waukesha engine VGF24GL-GLD

Technical Data

Waukesha engine configuration
H24SEU - rich burn combustion, low fuel pressure, ESM control
H24GLU - lean combustion, standard fuel pressure
H24GLDU - lean combustion, low fuel pressure
Cylinders Inline 8
Piston Displacement 1,462 cu. in. (24 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 20 gal. (75 L)
Lube oil capacity 56 gal. (212 L)
Fuel Pressure Range GLU - 26 - 50 psig (1.79 - 3.45 bar)
GLDU - 8”- 20” W.C. (2 - 5 kPa)
SEU - 1.5 - 5 psig (10.3 - 34.5 kPa)
Dimensions l x w x h inch (mm) 126 (3,200) x 96 (2,413) x 121 (3,073)
Weights lb (kg) 13,300 (6,033)

VGF H24SEU/GLU/GLDU

Gas power unit
345 – 560 BHP (257 – 417 kWb)
waukesha engine VGF-H24SEU-GLU-GLDU

Technical Data

Waukesha engine
P48GL/GLD
Cylinders V16
Piston Displacement 2,924 cu. in. (48 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 58 gal. (219 L)
Lube oil capacity 113 gal. (428 L)
Starting system 24V DC electric
Dimensions l x w x h inch (mm) Water cooler
176 (4,470) x 68 (1,720) x 96 (2,440)
Radiator
228 (5,790) x 105 (2,670) x 136 (3,230)
Weights lb (kg) Water connection 23,000 (10,440)
Radiator 30,200 (13,700)

VGF48GL/GLD

Enginator generating system
670 - 860 kWe
waukesha engine VGF48GL-GLD

Technical Data

Waukesha engine configuration
F18SEU - rich burn combustion, low fuel pressure, ESM control
F18GLU - lean combustion, standard fuel pressure
F18GLDU - lean combustion, low fuel pressure
Cylinders Inline 6
Piston Displacement 1,096 cu. in. (18 L)
Compression ration 11:1 (8.6:1 SE)
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 37 gal. (140 L)
Lube oil capacity 44 gal. (166 L)
Fuel Pressure Range GLU - 26-50 psig (1.79-3.45 bar)
GLDU - 8”-20” W.C. (2-5 kPa)
SEU - 1.5-5 psig (10.3-34.5 kPa)
Dimensions l x w x h inch (mm) 116 (2950) x 78 (1981) x 98 (2489)
Weights lb (kg) 9200 (4173)

VGF F18SEU/GLU/GLDU

Gas power unit
300 – 418 BHP (224 – 312 kWb)
waukesha engine VGF-F18SEU-GLU-GLDU

Technical Data

Waukesha engine configuration
L5794GSI, four cycle
Cylinders V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 8.25:1
Bore & stroke 8.5” x 8.5” (216 mm x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)/
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP5904GSI

Enginator generating system
with ESM2 and emPact Emission Control System
860 - 980 kW
waukesha engine VHP-Series-Four-VHP5904GSI

Technical Data

Waukesha engine configuration
P9394GSI, four cycle
Cylinders V16
Piston Displacement 9,388 cu. in. (154 L)
Compression ration 9.7:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216mm)
Jacket water system capacity 148 gal. (560 L)
Lube oil capacity 239 gal. (904 L)
Starting system 2 electric starters, 24V each
Dimensions l x w x h inch (mm) 263 (6,666) x 80 (2,019) x 141 (3,578)
Weights lb (kg) 60,400 (27,400)

VHP Series Five VHP9504GSI S5

Enginator generating system
1,785 kWe (60 Hz)
1,600 kWe (50 Hz)
waukesha engine VHP-Series-Five-VHP9504GSI-S5

Technical Data

Waukesha engine configuration
L7044GSI, four cycle
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP7104GSI

Enginator generating system
with ESM2 and emPact Emission Control System
1,050 - 1,200 kW
waukesha engine VHP-Series-Four-VHP7104GSI

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalyst-out exhaust piping shown for illustrative purposes only.

Technical Data

Waukesha engine configuration
L5794LT, four cycle, overhead valve
Cylinders V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 10.2:1
Bore & stroke 8.5” x 8.5” (216 mm x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Fuel Pressure Range 25 - 50 psi (1.72 - 3.45 bar)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP5904LT

Enginator generating system
with ESM2 and emPact Emission Control System
860 - 1,025 kW
waukesha engine VHP-Series-Four-VHP5904LT

Technical Data

Waukesha engine configuration
F3524GSI, four cycle
Cylinders Inline 6
Piston Displacement 3,520 cu. in. (58 L)
Compression ration 8:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 48.5 gal. (184 L)
Lube oil capacity 72 gal. (273 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
205 (5,260) x 68 (1,730) x 106 (2,690)
Water connection
188 (4,780) x 66 (1,680) x 106 (2,690)
Radiator
217 (5,510) x 85 (2,160) x 124 (3,150)
Weights lb (kg) Heat exchanger 24,750 (11,225)
Water connection 23,750 (10,775)
Radiator 27,500 (12,475)

VHP Series Four VHP3604GSI

Enginator generating system
with ESM2 and emPact Emission Control System
500 - 600 kW
waukesha engine VHP-Series-Four-VHP3604GSI

Technical Data

Waukesha engine configuration
L7044GSI S5, four cycle with Low Fuel Pressure System
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 9.7:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Minimum Fuel Pressure 1.7 psig (11.7 kPa)
Dimensions l x w x h inch (mm) Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Weights lb (kg) Water connection 42,400 (19,232)

VHP Series Five VHP7104GSID S5

With Low Fuel Pressure System
ESM2 and emPact Emission Control Systems
1,235 kWe @ 1,000 rpm for 50 Hz Applications
waukesha engine VHP-Series-Five-VHP7104GSID-S5

Technical Data

Waukesha engine configuration
L7042GSI S4, four cycle
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP7100GSI S4

Enginator generating system
with ESM2 and emPact Emission Control System
835 - 1,050 kW
waukesha engine VHP-Series-Four-VHP7100GSI-S4

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalyst-out exhaust piping shown for illustrative purposes only.

Technical Data

Waukesha engine configuration
L5794LT, four cycle, overhead valve
Cylinders V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 10.2:1
Bore & stroke 8.5” x 8.5” (216 mm x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP5904LTD

Enginator generating system
860 - 1,025 kW
waukesha engine VHP-Series-Four-VHP5904LTD

Technical Data

Waukesha engine configuration
P9394GSI, four cycle
Cylinders V16
Piston Displacement 9,388 cu. in. (154 L)
Compression ration 9.7:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216mm)
Jacket water system capacity 148 gal. (560 L)
Lube oil capacity 239 gal. (904 L)
Starting system 2 electric starters, 24V each
Dimensions l x w x h inch (mm) 263 (6,666) x 80 (2,019) x 141 (3,578)
Weights lb (kg) 60,400 (27,400)

VHP Series Four VHP5904LTD

Enginator generating system
1,600 kWe (60 Hz)
1,460 kWe (50 Hz)
waukesha engine VHP-Series-Four-VHP9504GSI

Technical Data

Waukesha
VHP7104GSI MOB
Cylinders V12
Piston Displacement 115 L (7,040 cu. in.)
Compression ration 8:1
Bore & stroke 238 x 216 mm (9.375’’ x 8.5’’)
Jacket water system capacity 379 L (100 gal.)
Lube oil capacity 719 L (190 gal.)
Starting system 620 - 1,034 kPa air/gas; optional 24V electric
Waukesha
VHP5904GSI MOB
Cylinders V12
Piston Displacement 95 L (5,788 cu. in.)
Compression ration 8.25:1
Bore & stroke 216 x 216 mm (8.5” x 8.5”)
Jacket water system capacity 405 L (107 gal.)
Lube oil capacity 719 L (190 gal.)
Starting system 620 - 1,034 kPa air/gas; optional 24V electric

VHP Series Four VHP5904/7104GSI-MOB

Multi-Fuel Mobile Power Generation
900/1,100 kWe (50Hz @ 1,000 rpm)
waukesha engine VHP-Series-Four-VHP5904-7104GSI-MOB

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalystout exhaust piping shownfor illustrative purposes only.

Technical Data

Waukesha
VHP7104GSI EPA
Cylinders V12
Piston Displacement 115 L (7,040 cu. in.)
Compression ration 8:1
Bore & stroke 238 x 216 mm (9.375’’ x 8.5’’)
Jacket water system capacity 379 L (100 gal.)
Lube oil capacity 719 L (190 gal.)
Starting system 620 - 1,034 kPa air/gas; optional 24V electric
Waukesha
VHP5904GSI MOB
Cylinders V12
Piston Displacement 95 L (5,788 cu. in.)
Compression ration 8.25:1
Bore & stroke 216 x 216 mm (8.5” x 8.5”)
Jacket water system capacity 405 L (107 gal.)
Lube oil capacity 719 L (190 gal.)
Starting system 620 - 1,034 kPa air/gas; optional 24V electric

VHP Series Four VHP5904/7104GSI-EPA

Multi-Fuel Mobile Power Generation
980/1,200 kWe (1,380/1,680 BHP)
waukesha engine VHP Series Four VHP5904-7104GSI-EPA

Engine supplied with 3-way catalyst but without exhaust piping. Engine-out and catalystout exhaust piping shownfor illustrative purposes only.

Technical Data

Waukesha engine
F3524GSID, four cycle
Cylinders Inline 6
Piston Displacement 3,520 cu. in. (58 L)
Compression ration 8:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 48.5 gal. (184 L)
Lube oil capacity 72 gal. (273 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
205 (5,260) x 68 (1,730) x 106 (2,690)
Water connection
188 (4,780) x 66 (1,680) x 106 (2,690)
Radiator
217 (5,510) x 85 (2,160) x 124 (3,150)
Weights lb (kg) Heat exchanger 24,750 (11,225)
Water connection 23,750 (10,775)
Radiator 27,500 (12,475)

VHP Series Four VHP3604GSID

Enginator generating system
500 - 600 kW
waukesha engine VHP-Series-Four-VHP3604GSID

Technical Data

Waukesha engine
L5794GSID, four cycle
Cylinders V12
Piston Displacement 5,788 cu. in. (95 L)
Compression ration 8.25:1
Bore & stroke 8.5” x 8.5” (216 mm x 216 mm)
Jacket water system capacity 107 gal. (405 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP5904GSID

Enginator generating system
860 - 980 kW
waukesha engine VHP-Series-Four-VHP5904GSID

Technical Data

Waukesha engine
L7042GSI S4, four cycle
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5” (238 mm x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP7100GSID S4

Enginator generating system
835 - 1,050 kW
waukesha engine VHP Series Four VHP7100GSID S4

Technical Data

Waukesha engine
L7044GSI, four cycle
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 8:1
Bore & stroke 9.375’’ x 8.5” (238 mm x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Heat exchanger
235 (5,970) x 85 (2,160) x 103 (2,620)
Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Radiator
260 (6,600) x 124 (3,150) x 160 (4,060)
Weights lb (kg) Heat exchanger 40,000 (18,140)
Water connection 38,000 (17,230)
Radiator 46,000 (20,860)

VHP Series Four VHP7104GSID

Enginator generating system
1,050 - 1,200 kW
waukesha engine VHP Series Four VHP7104GSID

Technical Data

Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 9.7:1
Bore & stroke 9.375’’ x 8.5” (238 mm x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Five L7044GSI S5

With ESM2 and emPact Emission Control System
1,900 BHP (1,416 kWb) @ 1,200 RPM
waukesha engine VHP-Series-Five-L7044GSI-S5

Technical Data

Cylinders
V16
Piston Displacement 9,388 cu. in. (154 L)
Compression ration 9.7:1
Bore & stroke 9.375’’ x 8.5” (238 mm x 216 mm)
Jacket water system capacity 148 gal. (560 L)
Lube oil capacity 239 gal. (904 L)
Starting system Single air/gas starter:
90-150 psi
Single air/gas starter:
50-90 psi
Dual air/gas starters:
90-150 psi
Dual air/gas starters:
50-90 psi
2 electric starters, 24V each
Dimensions l x w x h inch (mm) 170 (4,318) x 78 (1,981) x 113 (2,870)
Weights lb (kg) 34,000 (15,422)

VHP Series Five P9394GSI S5

With ESM2 and emPact Emission Control System
1,875 - 2,500 hp (1,400 - 1,865 kWb)
waukesha engine VHP-Series-Five-P9394GSI-S5

Technical Data

Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 9.7:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 125 - 150 psi air/gas 24V electric
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Five L7042GSI S5

With ESM2 and emPact Emission Control System
1,500 BHP (1,119 kWb) @ 1,200 RPM
waukesha engine VHP-Series-Five-L7042GSI-S5

Technical Data

Cylinders
V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 9.7:1
Bore & stroke 9.375’’ x 8.5’’ (238 x 216mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 125 - 150 psi air/gas 24V electric
Minimum Fuel Pressure 1.7 psig (11.7 kPa)
Dimensions l x w x h inch (mm) 147 (3,734) x 85 (2,159) x 97.83 (2,485)
Weights lb (kg) 24,250 (11,000)

VHP Series Five L7044GSI S5

With Low Fuel Pressure System
ESM2 and emPact Emission Control Systems
1235 kWe @ 1000 rpm for 50 Hz PG Applications
1743 hp (1300 kWb)
waukesha engine VHP-Series-Five-L7044GSI-S5

Technical Data

Cylinders
V16
Piston Displacement 2,924 cu. in. (48 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 58 gal. (219 L)
Lube oil capacity 113 gal. (428 L)
Low Fuel Pressure Range (According to regulator used) 8” WC - 5-psig (0.02 - 0.34 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 115.12 (2,924) x 61.38 (1,559) x 79.72 (2,025)
Weights lb (kg) 14,900 lbs. (6,760 kg)

VGF P48GSID

830-1,065 BHP (620-800 kWb)
waukesha engine VGF-P48GSID

Technical Data

Cylinders
V16
Piston Displacement 2,924 cu. in. (48 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 58 gal. (219 L)
Lube oil capacity 113 gal. (428 L)
Fuel Pressure Range 25 - 50 psi (1.72 - 3.45 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 114.61 (2,911) x 61.38 (1,559) x 79.72 (2,025)
Weights lb (kg) 14,900 lbs. (6,760 kg)

VGF P48GSI

830-1,065 BHP (620-800 kWb)
waukesha engine VGF-P48GSI

Technical Data

Cylinders
V16
Piston Displacement 2,924 cu. in. (48 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 58 gal. (219 L)
Lube oil capacity 113 gal. (428 L)
Low Fuel Pressure Range (According to regulator used) 8” WC - 5-psig (0.02 - 0.34 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 114.61 (2,911) x 61.38 (1,559) x 79.72 (2,025)
Weights lb (kg) 14,900 lbs. (6,760 kg)

VGF P48GLD

710-1,175 BHP (530-880 kWb)
waukesha engine VGF-P48GLD

Technical Data

Cylinders
V16
Piston Displacement 2,924 cu. in. (48 L)
Compression ration LCR 8.7:1, HCR 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 58 gal. (219 L)
Lube oil capacity 113 gal. (428 L)
Fuel Pressure Range 25 - 50 psi (172 - 345 kPa)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 114.61 (2,911) x 61.38 (1,559) x 79.72 (2,025)
Weights lb (kg) 14,900 lbs. (6,760 kg)

VGF P48GL

710-1,175 BHP (530-880 kWb)
waukesha engine VGF-P48GL

Technical Data

Cylinders
V12
Piston Displacement 2,193 cu. in. (36 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 44 gal. (166 L)
Lube oil capacity 86 gal. (326 L)
Low Fuel Pressure Range (According to regulator used) 8” WC - 5-psig (0.02 - 0.34 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 96.62 (2,454) x 61.38 (1,559) x 79.72 (2,025)
Weights lb (kg) 11,200 (5,080)

VGF L36GSID

620-800 BHP (460-600 kWb)
waukesha engine VGF-L36GSID

Technical Data

Cylinders
V12
Piston Displacement 2,193 cu. in. (36 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 44 gal. (166 L)
Lube oil capacity 86 gal. (326 L)
Fuel Pressure Range 25 - 50 psi (1.72 - 3.45 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 88 (2,235) x 61.97 (1,574) x 73.11 (1,857)
Weights lb (kg) 11,200 (5,080)

VGF L36GSI

620 - 800 BHP (460 - 600 kWb)
waukesha engine VGF-L36GSI

Technical Data

Cylinders
V12
Piston Displacement 2,193 cu. in. (36 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 44 gal. (166 L)
Lube oil capacity 86 gal. (326 L)
Low Fuel Pressure Range (According to regulator used) 8” WC - 5 psig (0.02 - 0.34 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 96.62 (2,454) x 61.38 (1,559) x 79.72 (2,025)
Weights lb (kg) 11,200 (5,080)

VGF L36GLD

620 - 880 BHP (460 - 660 kWb)
waukesha engine VGF-L36GLD

Technical Data

Cylinders
V12
Piston Displacement 2,193 cu. in. (36 L)
Compression ration LCR 8.7:1 HCR 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 44 gal. (166 L)
Lube oil capacity 86 gal. (326 L)
Fuel Pressure Range 25 - 50 psi (172 - 345 kPa)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 88 (2,235) x 61.97 (1,574) x 73.11 (1,857)
Weights lb (kg) 11,200 (5,171)

VGF L36GL

620 - 880 BHP (460 - 660 kWb)
waukesha engine VGF-L36GL

Technical Data

Cylinders
Inline 8
Piston Displacement 1,462 cu. in. (24 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 20 gal. (75 L)
Lube oil capacity 56 gal. (212 L)
Low Fuel Pressure Range (According to regulator used) 8” WC - 5 psig (0.02 - 0.34 bar)
Starting system 150 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 96.6 (2,453) x 51 (1,294) x 68.4 (1,737)
Weights lb (kg) 7,500 (3,400)

VGF H24GLD

355 - 585 BHP (265 - 440 kWb)
waukesha engine VGF-H24GLD

Technical Data

Cylinders
Inline 8
Piston Displacement 1,462 cu. in. (24 L)
Compression ration LCR 8.7:1, HCR 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 20 gal. (75 L)
Lube oil capacity 56 gal. (212 L)
Fuel Pressure Range 25 - 50 psi (1.72 - 3.45 bar)
Starting system 120 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 96.5 (2,451) x 50 (1,264) x 68 (1,727)
Weights lb (kg) 7,500 (3,400)

VGF H24GL

355 - 585 BHP (265 - 440 kWb)
waukesha engine VGF-H24GL

Technical Data

Cylinders
Inline 8
Piston Displacement 1,462 cu. in. (24 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 20 gal. (75 L)
Lube oil capacity 56 gal. (212 L)
Fuel Pressure Range 1.5 - 5.0 psig (0.1 - 0.34 bar)
Starting system 120 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 96.5 (2,453) x 48 (1,218) x 68.4 (1,737)
Weights lb (kg) 8,300 (3,773)

VGF H24SE

With emPact Emission Control System
415 - 530 BHP (310 - 400 kWb)
waukesha engine VGF-H24SE

Technical Data

Cylinders
Inline 6
Piston Displacement 1,096 cu. in. (18 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 16 gal. (60 L)
Lube oil capacity 44 gal. (166 L)
Low Fuel Pressure Range (According to regulator used) 8” WC - 5 psig (0.02 - 0.34 bar)
Starting system 120 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 80.5 (2,043) x 50 (1,264) x 68 (1,727)
Weights lb (kg) 6,400 (2,903)

VGF F18GLD

310 - 440 BHP (230 - 330 kWb)
waukesha engine VGF-F18GLD

Technical Data

Cylinders
Inline 6
Piston Displacement 1,096 cu. in. (18 L)
Compression ration LCR 8.7:1, HCR 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 16 gal. (60 L)
Lube oil capacity 44 gal. (166 L)
Fuel Pressure Range 25 - 50 psi (1.72 - 3.45 bar)
Starting system 120 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 80.5 (2,043) x 50 (1,264) x 68 (1,727)
Weights lb (kg) 6,200 (2,812)

VGF F18GL

310 - 440 BHP (230 - 330 kWb)
waukesha engine VGF-F18GL

Technical Data

Cylinders
Inline 6
Piston Displacement 1,096 cu. in. (18 L)
Compression ration 8.6:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 16 gal. (60 L)
Lube oil capacity 44 gal. (166 L)
Fuel Pressure Range 1.5 - 5.0 psig (0.1 - 0.34 bar)
Starting system 120 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 80.5 (2,043) x 48 (1,218) x 68.4 (1,737)
Weights lb (kg) 6,900 (3,136)

VGF F18SE

310-400 BHP (230-300 kWb)
With emPact Emission Control System
waukesha engine VGF-F18SE

Technical Data

Cylinders
Inline 6
Piston Displacement 1,096 cu. in. (18 L)
Compression ration 11:1
Bore & stroke 5.98” x 6.5” (152 x 165 mm)
Jacket water system capacity 16 gal. (60 L)
Lube oil capacity 44 gal. (166 L)
Fuel Pressure Range 5 - 15 psi (0.34 - 1.03 bar)
Starting system 120 psi max. air/gas 24V DC electric
Dimensions l x w x h inch (mm) 80.5 (2,043) x 50 (1,264) x 68 (1,727)
Weights lb (kg) 5300 (2,400)

VGF F18G

310-400 BHP (230-300 kWb)
waukesha engine VGF-F18G

Technical Data

Waukesha engine
L7044GSI S5, four cycle
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 9.7:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Weights lb (kg) Water connection 38,000 (17,230)

VHP Series Five VHP7104GSI S5

Enginator generating system
with ESM2 and emPact Emission Control System
1,235 - 1,350 kWe
waukesha engine VHP-Series-Five-VHP7104GSI-S5

Technical Data

Waukesha engine
L7042GSI S5, four cycle
Cylinders V12
Piston Displacement 7,040 cu. in. (115 L)
Compression ration 9.7:1
Bore & stroke 9.375” x 8.5” (238 x 216 mm)
Jacket water system capacity 100 gal. (379 L)
Lube oil capacity 190 gal. (719 L)
Starting system 24V electric
Dimensions l x w x h inch (mm) Water connection
205 (5,208) x 85 (2,160) x 103 (2,620)
Weights lb (kg) Water connection 38,000 (17,230)

VHP Series Five VHP7100GSI S5

Enginator generating system
with ESM2 and emPact Emission Control System
1,005 - 1,065 kWe
waukesha engine VHP-Series-Five-VHP7100GSI-S5
